MM-400A
12. Data Communication
12-49
Item Display Range Length
78 Output 10 -1 26 (External output 1 to 12 code table) 2
79 Delimiter , 1
80 Output 10 -2 62 (External output 1 to 12 code table) 2
81 Delimiter , 1
82 Output 10 -3 62 (External output 1 to 12 code table) 2
83 Delimiter , 1
84 Output 11 -1 27 (External output 1 to 12 code table) 2
85 Delimiter , 1
86 Output 11 -2 62 (External output 1 to 12 code table) 2
87 Delimiter , 1
88 Output 11 -3 62 (External output 1 to 12 code table) 2
89 Delimiter , 1
90 Output 12 -1 62 (External output 1 to 12 code table) 2
91 Delimiter , 1
92 Output 12 -2 62 (External output 1 to 12 code table) 2
93 Delimiter , 1
94 Output 12 -3 62 (External output 1 to 12 code table) 2
95 Delimiter , 1
96 PARITY 0 0: OFF
1: ON
1
97 Delimiter , 1
98 INPUT DELAY
TIME
0 0: 1ms
1: 10ms
1
99 Delimiter , 1
100 NG OUTPUT
MODE
0 0: NORMALLY CLOSED
1: NORMALLY OPEN
1
101 Delimiter , 1
102 OUTPUT TIME 0 0: 10ms
1: 100ms
2: HOLD
1
103 Delimiter , 1
104 LEVEL OUTPUT 0 0: LEVEL
1: PULSE
1
105 Return code [CR] (0x0d) 1
106 Feed code [LF] (0x0a) 1
 Output data (SCH.# 000)
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
4 Screen code S 1
