12. Data Communication
12-59
10) USB [Item No. 23]
 Writing request data (SCH.# 000)
Item
Display
Range
Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 000 000 3
5 Screen code S 1
6 Item No. 23 2
7 Delimiter : 1
8 Item 0 0: OFF
1: MEASUREMENT
2: WAVEFORM
3: CURRENT ALL CYCLE
4: FORCE ALL CYCLE
5: HISTORY
6: HISTORY OUTOF LIM
7: SCHEDULE
8: SCREEN
9: ENVELOPE
1
9 Delimiter , 1
10 INTERVAL 0001 0001 to 1000 4
11 Delimiter , 1
12 OUT OF LIMIT
OPERATION
0 0: OFF
1: ON
1
13 Delimiter , 1
14 WAVE DECIMATION 0 0: 20us
1: 50us
2: 100us
3: 200us
4: 500us
5: 1000us
1
15 Delimiter , 1
16 UNIT 0 0: OFF 1: ON 1
17 Delimiter , 1
18 DECIMAL POINT
RANGE
0 0: . (period) 1: , (comma) 1
19 Return code [CR] (0x0d) 1
20 Feed code [LF] (0x0a) 1
 Output data (SCH.# 000)
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
