MM-400A
12. Data Communication
12-61
11) INTERNAL MEMORY [Item No. 24]
 Writing request data (SCH.# 000)
Item
Display
Range
Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 000 000 3
5 Screen code S 1
6 Item No. 24 2
7 Delimiter : 1
8 ITEM 0 0: OFF
1: WAVEFORM
2: CURRENT ALL CYCLE
3: FORCE ALL CYCLE
1
9 Delimiter , 1
10 INTERVAL 0001 0001 to 1000 4
11 Delimiter , 1
12 OUT OF LIMIT
OPERATION
0 0: OFF
1: ON
1
13 Delimiter , 1
14 WAVE DECIMATION 0 0: 20us
1: 50us
2: 100us
3: 200us
4: 500us
5: 1000us
1
15 Return code [CR] (0x0d) 1
16 Feed code [LF] (0x0a) 1
 Output data (SCH.# 000)
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
4 Screen code S 1
5 Item No. 24 2
6 Delimiter : 1
7 ITEM 0 0: OFF
1: WAVEFORM
2: CURRENT ALL CYCLE
3: FORCE ALL CYCLE
1
8 Delimiter , 1
9 INTERVAL 0001 0001 to 1000 4
10 Delimiter , 1
