Amada WELD CHECKER MM-400A - Page 284

MM-400A
12. Data Communication
12-63
12) ENVELOPE [Item No. 17]
 Output data for each schedule 001 to 020
Item
Display
Range
Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 020 3
4 Screen code S 1
5 Item No. 17 2
6 Delimiter : 1
7 OFFSET UPPER
ENVE#1 SEGM#1
(Refer to the envelope upper/lower limit table.) 11
8 Delimiter , 1
9 OFFSET UPPER
ENVE#1 SEGM#2
(Refer to the envelope upper/lower limit table.) 11
10 Delimiter , 1
11 OFFSET UPPER
ENVE#1 SEGM#3
(Refer to the envelope upper/lower limit table.) 11
12 Delimiter , 1
13 OFFSET UPPER
ENVE#2 SEGM#1
(Refer to the envelope upper/lower limit table.) 11
14 Delimiter , 1
15 OFFSET UPPER
ENVE#2 SEGM#2
(Refer to the envelope upper/lower limit table.) 11
16 Delimiter , 1
17 OFFSET UPPER
ENVE#2 SEGM#3
(Refer to the envelope upper/lower limit table.) 11
18 Delimiter , 1
19 OFFSET LOWER
ENVE#1 SEGM#1
(Refer to the envelope upper/lower limit table.) 11
20 Delimiter , 1
21 OFFSET LOWER
ENVE#1 SEGM#2
(Refer to the envelope upper/lower limit table.) 11
22 Delimiter , 1
23 OFFSET LOWER
ENVE#1 SEGM#3
(Refer to the envelope upper/lower limit table.) 11
24 Delimiter , 1
25 OFFSET LOWER
ENVE#2 SEGM#1
(Refer to the envelope upper/lower limit table.) 11
26 Delimiter , 1
27 OFFSET LOWER
ENVE#2 SEGM#2
(Refer to the envelope upper/lower limit table.) 11
28 Delimiter , 1
29 OFFSET LOWER
ENVE#2 SEGM#3
(Refer to the envelope upper/lower limit table.) 11
