Amada WELD CHECKER MM-400A - Page 286

MM-400A
12. Data Communication
12-65
Item Display Range Length
59 END TIME UPPER
ENVE#1 SEGM#3
00000ms 00000 to 10000ms 7
60 Delimiter , 1
61 END TIME UPPER
ENVE#2 SEGM#1
00000ms 00000 to 10000ms 7
62 Delimiter , 1
63 END TIME UPPER
ENVE#2 SEGM#2
00000ms 00000 to 10000ms 7
64 Delimiter , 1
65 END TIME UPPER
ENVE#2 SEGM#3
00000ms 00000 to 10000ms 7
66 Delimiter , 1
67 END TIME LOWER
ENVE#1 SEGM#1
00000ms 00000 to 10000ms 7
68 Delimiter , 1
69 END TIME LOWER
ENVE#1 SEGM#2
00000ms 00000 to 10000ms 7
70 Delimiter , 1
71 END TIME LOWER
ENVE#1 SEGM#3
00000ms 00000 to 10000ms 7
72 Delimiter , 1
73 END TIME LOWER
ENVE#2 SEGM#1
00000ms 00000 to 10000ms 7
74 Delimiter , 1
75 END TIME LOWER
ENVE#2 SEGM#2
00000ms 00000 to 10000ms 7
76 Delimiter , 1
77 END TIME LOWER
ENVE#2 SEGM#3
00000ms 00000 to 10000ms 7
78 Return code [CR] (0x0d) 1
79 Feed code [LF] (0x0a) 1
 Output data common to all schedules (SCH.# 000)
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
4 Screen code S 1
5 Item No. 17 2
6 Delimiter : 1
7 COMPARATOR MODE 0 0: % SET
1: VALUE SET
1
8 Delimiter , 1
