MM-400A
12. Data Communication
12-71
5) Envelope upper/lower limit code table
 % SET
Item
code
Item name
Measured value (*)
Unit
(*)
Display Range Length
CURRENT
VOLTAGE
POWER
RESISTANCE
DISPLACEMENT
FORCE
EXTERNAL
No setting
+000000%___ -000050 to +000050%___ 11 %___
* A space falls into “_” for digit matching.
 VALUE SET
Item
code
Item name Measured value (*)
Unit
(*)
Display Range Length
0 CURRENT +00.000kA__
+000.00kA__
+0000.0kA__
-09.999 to +09.999kA__
-099.99 to +099.99kA__
-0999.9 to +0999.9kA__
11 kA__
1 VOLTAGE +000.00V___
+0000.0V___
-009.99 to +009.99V___
-0099.9 to +0099.9V___
11 V___
2 POWER +000.00kW__ -300.00 to +300.00kW__ 11 kW__
3 RESISTANCE +000.00mOhm -300.00 to +300.00mOhm 11 mOhm
4 DISPLACEMENT +00.000mm__
+000.00mm__
+0.0000inch
+00.000inch
-30.000 to +30.000mm__
-300.00 to +300.00mm__
-3.0000 to +3.0000inch
-30.000 to +30.000inch
11 mm__
inch
5 FORCE +000.00N___
+0000.0N___
+000000N___
-099.99 to +099.99N___
-0999.9 to +0999.9N___
-009999 to +009999N___
11 N___
kgf_
lbf_
6 EXTERNAL +00.000degC
+000.00degC
+0000.0degC
+000000degC
-09.999 to +09.999degC
-099.99 to +099.99degC
-0999.9 to +0999.9degC
-009999 to +009999degC
11 ____
V___
N___
kgf_
lbf_
degC
degF
Mpa_
bar_
psi_
* A space falls into “_” for digit matching.
