17. Schedule Data Table
17-8
Setting
screen
Setting item Initial value SCH SCH SCH SCH
SEAM
SETUP
(1)
SCHEDULE NAME
START MEASUREMENT
000.0CYC
MEASUREMENT
RANGE
0.5CYC
MEASUREMENT
INTERVAL
00.5CYC
START TIME 1
00000.0CYC
END TIME 1
15000.0CYC
START TIME 2
00000.0CYC
END TIME 2
15000.0CYC
START TIME 3
00000.0CYC
END TIME 3
15000.0CYC
SEAM
SETUP
(2)
CURRENT 1 LOWER
00.00kA
CURRENT 1 UPPER
99.99kA
CURRENT 2 LOWER
00.00kA
CURRENT 2 UPPER
99.99kA
CURRENT 3 LOWER
00.00kA
CURRENT 3 UPPER
99.99kA
VOLTAGE 1 LOWER
00.0V
VOLTAGE 1 UPPER
99.9V
VOLTAGE 2 LOWER
00.0V
VOLTAGE 2 UPPER
99.9V
VOLTAGE 3 LOWER
00.0V
VOLTAGE 3 UPPER 99.9V
SEAM
SETUP
(3)
TRIGGER
CURRENT
TIME
CYC-AC
CALCULATION
ORIGINAL
CURRENT RANGE
20.00kA
VOLTAGE RANGE
20.0V
CURRENT TRIGGER
LEVEL
90
TOROIDAL COIL
TIMES 1
END LEVEL
05.0%
