MM-400A
8. Operation Screens
8-53
Column Item Display/contents
AE Judgment item code 10 Refer to the Judgment code table.
AF Measured value 10
AG ENVELOPE#1 Waveform
item code
Refer to the Waveform code table
(Item code).
AH ENVELOPE#1 SEGMENT#1
Judgment
Refer to the Judgment code table.
AI ENVELOPE#1 SEGMENT#2
Judgment
Refer to the Judgment code table.
AJ ENVELOPE#1 SEGMENT#3
Judgment
Refer to the Judgment code table.
AK ENVELOPE#2 Waveform
item code
Refer to the Waveform code table
(Item code).
AL ENVELOPE#2 SEGMENT#1
Judgment
Refer to the Judgment code table.
AM ENVELOPE#2 SEGMENT#2
Judgment
Refer to the Judgment code table.
AN ENVELOPE#2 SEGMENT#3
Judgment
Refer to the Judgment code table.
• The data contents of CURRENT ALL CYCLE “curr_allcycle_*.csv” (* indicates 0
to 1000) are as follows.
Column/Cell
Item
Display/range
A Current flow time In unit(s) of 1 ms or 0.5 CYC
B
Measurement
range
Shows * for measurement range and space for
non-measurement range.
C Current value
Shows current value for every current flow
time.
D Voltage value
Shows voltage value for every current flow
time.
C1
Number of
measurements
Shows the number of all cycle data.
• The data contents of FORCE ALL CYCLE “force_allcycle_*.csv” (* indicates 0 to
1000) are as follows.
Column/Cell Item Display/range
A Current flow time In units of 10 ms
B
Measurement
range
Shows * for force measurement range and
space for non-measurement range.
C Force value Shows force value for every 10 ms.
D
Measurement
range
Shows * for external output measurement
range and space for non-measurement range.
E
External output
value
Shows external output value for every 10 ms.
C1
Number of
measurements
Shows the number of all cycle data.
