Chapter 7 Remote Commands
7-26
:DEMux:CLOCk:PDELay<numeric>
Parameter <numeric>=<DECIMAL NUMERIC PROGRAM DATA>
–20 to 20 –20 to 20 ps/0.08ps Steps (at 50 GHz)
–17.85 to 17.85 –17.85 to 17.85 ps/0.08ps Steps (at 56 GHz)
–15.62 to 15.62 –15.62 to 15.62 ps/0.08ps Steps (at 64 GHz)
Converted from the calculated frequency value, based on the setting
resolution of mUI.
Function Sets the variable clock input phase in ps units. The value specified in ps
units may not be set exactly due to resolution. In this event, the most
approximate value is set.
Example To set the variable clock phase of Data Interface to –40 ps:
> :DEMux:CLOCk:PDELay -40
Compatibility Compatible with MU182040A and MU182041A.
:DEMux:CLOCk:PDELay?
Parameter <interface>=<DECIMAL NUMERIC PROGRAM DATA>
Response <numeric>=<NR1 NUMERIC RESPONSE DATA>
Function Queries clock input phase variation and units.
Example To query Data Interface clock phase variation in ps units:
> :DEMux:CLOCk:PDELay?
< -40
Compatibility Compatible with MU182040A and MU182041A.
:DEMux:CLOCk:CALibration
Parameter <interface>=<DECIMAL NUMERIC PROGRAM DATA>
Function Calibrates input clock phase setting.
Example To calibrate Data Interface input clock phase setting:
> :DEMux:CLOCk:CALibration
Compatibility Compatible with MU182040A and MU182041A.
:DEMux:CLOCk:RELative <boolean>
Parameter <boolean>=<BOOLEAN PROGRAM DATA>
0 or OFF Reference OFF
1 or ON Reference ON
Function Sets clock input phase variation reference ON/OFF.
Example To set Data Interface clock input phase variation reference to ON:
> :DEMux:CLOCk:RELative ON
Compatibility Compatible with MU182040A and MU182041A.
