Chapter 3 Measurement
3-52
■
Options
1 Hz Displays the RF Frequency result in 1 Hz.
0.1 Hz Displays the RF Frequency result in 0.1 Hz.
0.01 Hz Displays the RF Frequency result in 0.01 Hz.
RF Power (W/mW) Resolution
■
Summary
Sets the resolution of RF Power measurement results.
■
Options
0.01 W/mW Displays the RF Power result in 0.01 W or 0.01 mW.
0.001 W/mW Displays the RF Power result in 0.001 W or 0.001 mW.
0.0001 W/mW Displays the RF Power result in 0.0001 W or
0.0001 mW.
3.4.8.5 Setting Modulation Display Mode
This section describes the settings for Modulation Display Mode. When
Display Mode is Modulation, press
(Modulation Setup) on the Trace
function menu to display the Modulation Setup function menu.
Deviation Type
■
Summary
Sets the type of analysis results to display on the Result window.
The following setting is common for all modulation modes.
● Deviation (Modulation is FM or Wide FM)
● Depth (Modulation is AM)
● Radian (Modulation is

M)
■
Options
RMS Displays the RMS result.
Peak+ Displays the Peak+ result.
Peak– Displays the Peak- result.
(Pk-Pk)/2 Displays the (Pk-Pk)/2 result.
Distortion Type
■
Summary
Sets the distortion type to display on the AF Measurement Result
(TX-AF) window.
■
Options
Distortion Displays the result of distortion (Distortion
Factor).
SINAD Displays the result of SINAD (Signal-to-Noise
and Distortion Ratio).
THD Displays the result of THD (Total Harmonic
Distortion).
