Table 5 – Slave 1 CAN Board Outputs
Pin Function Device Electro
Valve
Port Antenna LED Control
Devices
Description
Out – 1 G7b EV14 A A7 1 Routine
Input –
Pass/Pit
Stop
(Pass A)
Controls the carriers at the
Routine sample input.
A carrier with a Routine sample
tube is diverted to Lane (Pass)
Releases carriers to supply
Priority Input carriers (Pit Stop).
Out – 2 D1 EV15 A
and
B
Routine
Input –
Pit stop
(Pit Stop
A)
Located at Routine input.
Routes carriers from Routine
sample input to Lane 2.
When activated, routes empty
carriers from routine input to
priority input queue.
Out – 3 G6 EV13 A A6 2 Output –
Pass
(Pass B)
Controls carriers exiting Lane 4
Out – 4 D2 EV4 A
and
B
Output –
Pit Stop
Controls both D2a and D2b
diverters.
When activated, opens Lane
1/3 and positions Lane 2/3 to
route carriers with new
samples from G7a or G8 to
Barcode gate G2.
When closed, routes carriers
with completed samples from
G5 to either the 4
th
lane (Off-
line) or Main track (On-line).
Out – 5 D3 EV12 A
and
B
Routes Off-line carriers to main
track
Out – 6 G8 EV16 A A8 8 Priority
Input –
Pass
(Pass)
Controls the carriers at the
Priority sample input.
Out – 7 G5 EV11 A A5 4 Exit –
Pass
(Pass)
Controls the routing of carriers
exiting Lane 2. Determines if:
The On-line carrier should be
routed to the APS track
The Off-line carrier with a new
sample should be routed to
Lane 1 for sampling.
The Off-line carrier with a
completed sample is routed to
Lane 4.
Out – 8 G7a EV10 B Routine
Input –
Pass/Pit
Stop
(Return)
Located at Routine input area
Controlled by release of
carriers at G7a to prevent
collisions
