i2000SR interface module Service Manual
Page 34 of 212 625798100.APS.5.doc
i2000SR IM Electrical Box startup
Figure 13 – i2000SR IM main switch
Figure 14 – i2000SR Keypad
No. Description
RUN button
PAUSE button with pause LED
STOP button
i2000SR IM can be started in Standalone Mode or in APS Mode.
