i2000SR interface module Service Manual
Page 42 of 212 625798100.APS.5.doc
Assembly Procedure
Prerequisite
The i2000SR IM is designed to be supported by the i2000SR
instrument. The following procedures must be performed on the
i2000SR:
Refer to the Architect i2000SR Service documentation
• Calibrate Processing area robotics
• Install LAS support bracket
• Move the i2000SR into the APS installation area
NOTE:
Before moving the i2000SR IM, ensure the i2000SR support
bracket is fully seated (down) into the front panel pockets.
If the bracket is mounted too high, the ability to aspirate
the minimum sample volume will be impacted.
NOTE:
Refer to the i2000SR service documentation as required.
• It is recommended to install the following parts on the
i2000SR before moving into position at the i2000SR IM:
− LLS Sample bracket and antenna
− LLS STAT bracket and antenna
− LLS antennae cover
− Window Closeout with Process module LUI Keypad
− Right and Left side covers
• Reference the provided Workcell layout schematic, at the
TMA to determine the location that the i2000SR IM is to be
installed.
Installation of the Instrument Indicator Light
(pole lamps)
• Shift the side top panel to the right to make space for the
pole support mounting (See
Figure 16
).
• Remove the Instrument Indicator Light (pole lamps) group
from the shipping platform.
• Attach the pole on the lateral side of the track extrusion
using the two bolts provided (See
Figure 16
).
• The status lamp connection cables should pass along the
track wire guide to the electrical box.
• Connect the Lamp R/Y/G cable to J2 on the electrical box.
