Service Manual i2000SR interface module
625798100.APS.5.doc Page 37 of 212
However during FSR troubleshooting, it will be required to
cycle the power of the APS. This action may impact the
standalone operation and the i2000SR will need to be
reset.
i2000SR IM Track Initialization
NOTE:
During initialization, all APS On-line carriers on the i2000SR
IM Lanes are routed to the APS Main Track. If the APS track
belts are not running, the carriers will collect at the large
disk at the output of the IM and impact the movement of
the D3 diverter.
To initialize the system in Standalone mode, press the RUN button
on the LUI keypad (See
Figure 14
). During IM initialization the
following occurs:
1. The IM Master Tag Reader Com port 1 establishes
communication with the i2000SR via the SCC LAS port. If the
communication is established, the LAS icon will be displayed on
the i2000SR SCC snapshot screen.
NOTE:
In the event of a misrouted carrier at either the Sample
(G4) or STAT (G3) aspiration point, the IM will communicate
with the i2000SR to stop the sample processing via the
Master Tag Reader board Port 2 and CLI port on the
i2000SR CLI port.
The communication link between port 2 and the i2000SR is not
verified during initialization.
2. Carriers on Lane 2 Gate G5 are routed so that all On-line
carriers are sent to the Main Track and all Off-line carriers to G6
at the left end of Lane 4
3. The carriers at Routine G7b and Priority G8 Input gates on
the Lane 3 are routed to Lane 4 gate G6.
4. The carriers at G6 on Lane 4 are released and routed via
G7b and D1 to build a queue of six (6) carriers at the Priority
Input gate G8.
5. After the Priority queue of six (6) carriers is built, a queue
of eleven (11) Routine Input carriers is collected at the Routine
Input gate (G7b). The remaining four (4) carriers are staged at the
Output gate (G6) on Lane 4. The expression “queues rebuilding” is
displayed putting the carriers in the condition shown in
Figure 2
.
6. All carriers at Gates G3 and G4 on Lane 1 are routed to
Lane 2 gate G5. The on-line carriers are then routed to the main
track and off-line carriers to gate G6 on lane.
