i2000SR interface module Service Manual
Page 40 of 212 625798100.APS.5.doc
Instructions for Assembly
This chapter describes the operations for opening the supplied
packing, removing protective packing, assembling parts and
guards, and safely restoring electrical and pneumatic connections.
Refer to the Abbott Accelerator APS Acceptance Testing
section in Appendix C of the Accelerator APS Service Manual.
During the installation of the i2000SR and i2000SR IM, ensure
that all checks have been verified.
i2000SR IM Parts Shipped
The i2000SR IM is shipped in one dedicated closed crate and
labeled as LN 07L32-01 (IBL0045). The pallet contains all the
components needed to install i2000SR Interface Module on a
Workcell with a properly configured track interface. The crate
may contain up to two i2000SR IM assemblies.
The content of the shipping crate varies depending on the type of
installation.
• For a new installation, the i2000SR IM Pneumatic panel
and i2000SR IM electrical box is shipped with the associated track
Tack Module Assembly (TMA) module and will not be included in
the crate.
• For a retrofit or upgrade of a site installed APS system, the
Pneumatic panel and the electrical box is shipped with the crate.
Table 6 – Case overall dimensions
Depth Width Height
mm (in) mm (in) mm (in)
1980 (77.95) 900 (35.43) 1010 (39.76)
Table 7 – Case weights
Case Content Total
kg (lbs) kg (lbs) kg (lbs)
100 (220)
18 (40) [i2000SR IM]
16 (35) [Electrical box]
6 (13) [Pneumatic panel]
10 (22) [accessories]
150 (331)
(if one module)
200 (441)
(if two modules)
