Architect i2000SR - Modify Instrument Setup.INI file

Service Manual i2000SR interface module
625798100.APS.5.doc Page 77 of 212
Modify Instrument Setup.INI file
Action Reference
1. Navigate to the D:\Accelerator \INI
directory. Open the Instrument-Setup.ini file.
2. Ensure that the contents for the
i2000SR is as below:
[I2000sr]
Instrument Type = I2000sr
Instrument Display Name = I2000sr
Instrument Family = Immunochemistry
Instrument Type Code = I2000sr
Parent Instrument Type Code = I2000
Routine Queue Length = 7
STAT Queue Length = 2
Buffer Overload = 999
NOTE: Definitions:
ROUTINE Queue is number of carriers that
can be queued at the Routine Gate (G4).
Changing this parameter will write a new
value to the Master Tag Reader board and
change the Standalone function of the IM.
STAT Queue is number of carriers that can
be queued at the STAT Gate (G3). Changing
this parameter will write a new value to the
Master Tag Reader board and change the
Standalone function of the IM.
Buffer Overload is the maximum number of
carriers that remain in reserve for use on
the track for that particular analyzer type.
This feature is not currently fully
implemented and will be enabled in a future
release of the APS software.
Buffer Overload = XXX Refer to the latest
release of the APS software.
NOTE:
After the i2000SR IM Gate Queues lengths
are changed, the change will not take affect
until the i2000SR IM power has been cycled
NOTE
The following are examples of the other
module types.
[NCCLS]
Instrument Type = NCCLS
Instrument Display Name = NCCLS
Instrument Family = Immunochemistry
Instrument Type Code = NCCLS
Buffer Overload Count = 999[
I2000]
Instrument Type = I2000
Instrument Display Name = I2000
Instrument Family = Immunochemistry
Instrument Type Code = I2000
Buffer Overload Count = 999
[c8000]Instrument Type = c8000
Instrument Display Name = c8000
Instrument Family = Clinical Chemistry
Instrument Type Code = c8000
Buffer Overload Count = 999
[Fusion]
Instrument Type = Fusion
Instrument Display Name = Fusion
Instrument Family = Clinical Chemistry
Instrument Type Code = Fusion
Instrument LAS Timeout = 60 5 300
Order These Tests Despite Zero Inventory =
950 951 952
Buffer Overload Count = 999
[c16000]
Instrument Type = c16000
Instrument Display Name = c16000
Instrument Family = Clinical Chemistry
Instrument Type Code = c16000
Buffer Overload Count = 30
Parent Instrument Type Code = c8000
If any of the above settings were incorrect and changed, reload all
INI files
• Shutdown the APS Software
• Turn Off the IOM UPS
• Wait 2 minutes
• Turn On the IOM UPS
