i2000SR interface module Service Manual
Page 38 of 212 625798100.APS.5.doc
7. The IM module verifies the communication with the
i2000SR analyzer via Master tag reader board port 1 and the
green lamp on the lamp pole will be turned ON.
8. When both the Priority and Routine Input Gate Status
LEDs are green and the IM pole lamp is green, the system is
ready to accept local tubes.
Rebuilding queues
Standalone Mode – press the STOP and then the RUN keys. At this
point, the LED under the PAUSE button on the keypad is turned
off and queues rebuilding starts.
APS Mode – Use the APS GUI Diagnostics Track screen,
Transportation Module – RFID Tag Readers – Instrument # screen
button to Reset IM.
Standalone mode initializing
In standalone mode, after the completion of the i2000SR IM
Electrical Box startup, the operator must press RUN on the LUI
panel to initialize the i2000SR IM track. After initialization, the IM
Master Tag Reader board monitors the i2000SR operational
status. When the analyzer is running and ready to process
samples, the Green Instrument Indicator Light on the pole is ON.
In this status, the IM is able to process tubes. The status of the IM
is monitored by the Firmware in the tag reader boards. The status
is communicated to the operator via the Routine and Priority
Input Status LEDs and the Instrument Indicator Light on the pole.
APS mode initializing
In APS mode, after the completion of the i2000SR IM Electrical
Box startup and i2000SR IM track initialization, the RUN
command is sent from APS software via the CAN bus. The APS
decides when to establish a communication link with the i2000SR
analyzer and enable the i2000SR IM RUN state.
The status of the IM is monitored by the Firmware in the tag
reader boards. The status is communicated to the operator via the
APS software, Routine and Priority Input Status LEDs, and the
Instrument Indicator Light on the pole.
i2000SR IM exercise mode
The exercise mode is used to test the functionality of the gates,
antennae, diverters, belts, and Input Gate Status LEDs. The IM
component and devices on the main track (G0, A0, D0, G1, A1 and
D3) are not exercised.
Exercise mode is enabled by first completing the i2000SR IM
Electrical Box startup in Stand Alone mode, initializing the
i2000SR IM track (pressing the RUN button) and then pressing
and holding the RUN button as the PAUSE button is pressed.
