Starting i2000SR IM in APS Mode
1. To start i2000SR IM in APS mode, perform the following:
2. With the APS Shutdown and OFF, turn the i2000SR / APS
switch to the APS position. Turn ON the APS Workcell UPS ON.
• This will supply +24 VDC from the CAN-board power bus
to the IM electrical box via J3.
3. The following actions occur during initialization:
• The IM barcode scanner beeps once and performs its
POST initialization check.
• The IM barcode scanner is configured and beeps twice.
• The IM Tag boards are initialized.
• IM Red Status lamp turns ON and then begins to blink.
• Routine input gate yellow LED is ON.
• Routine input gate green LED is OFF.
• Priority input gate yellow LED is ON.
• Priority input gate green LED is OFF.
• The communication between the IM Master Tag Reader
board communication port 1 and the LAS COM port on the
SCC of the i2000SR is established. The i2000SR SCC LAS
communication is via Edgeport port 4 (Com 6).
• The Red Lamp stops blinking and remains ON when the
communication between the IM Master Tag Reader board
communication port 2 and the CLI COM port on the SCC
of the i2000SR is established. The i2000SR SCC CLI
communication is via Edgeport port 1 (Com 3).
4. Turn on the APS computer.
NOTE:
During ACCELERATOR APS logo screen, the LEDs on the
Power Distribution will illuminate and the IOM pneumatic
air valve will open. As i2000SR IM air supply is routed from
the IOM pneumatic panel manifold, its air supply is not
routed through the air valve.
5. At the Accelerator APS GUI screen, if the i2000SR
Analyzer is On-Line the i2000SR IM Track will be initialized. Refer
to i2000SR IM track Initialization.
NOTE:
During the APS mode the IM is controlled by the APS GUI
and the samples are entered at the IM routine and priority
inputs. Although the IM Local User Interface (LUI) keypad is
active it should not be used.
