Starting i2000SR IM in Standalone Mode
The standalone mode is used when the APS Workcell is not
operational.
To start i2000SR IM in i2000SR Standalone Mode (i2000SR),
perform the following steps:
1. Put the i2000SR IM main switch in “i2000 SR” position.
• When the switch is in “i2000SR” position, the +24 VDC
power supply in the i2000SR IM Electrical Box is used to
supply the IM devices. The IM +24 VDC power supply is
supplied by external AC power via J4. When the cable
connected to J4 is connected to an AC power source, the
+24 VDC power supply remains ON.
NOTE:
The power to the +24 VDC power supply in the electronic
box remains on at all times and is not controlled by the
i2000SR/0/APS switch. This power supply is protected by
the circuit breaker in the electronic box. It is recommended
to use the same AC power source for both the i2000SR
analyzer and IM systems. A UPS is advised.
2. The IM Electrical Box is initialized.
• The IM barcode scanner beeps once and performs its
POST initialization check.
• The IM barcode scanner is configured and beeps twice.
• The IM Tag boards are initialized.
• The IM Red Status lamp turns ON
• The Routine input gate yellow LED is on.
• The Routine input gate green LED is off.
• The Priority input gate yellow LED is on.
• The Priority input gate green LED is off.
• The communication between the IM Master Tag Reader
board communication port 1 and the LAS COM port on
SCC of the i2000SR is established. The i2000SR SCC
Edgeport connection is communication port 4.
• Pause LED is on the i2000SR keypad is ON (See
Figure
14
).
3. The operator control is provided by the LUI (Local User
Interface) keypad. The APS software is not used.
4. To initialize the i2000SR IM, press the Green START
button on the LUI keypad.
NOTE:
During standalone operation, the APS system must be OFF.
