Service Manual i2000SR interface module
625798100.APS.5.doc Page 145 of 212
Replacement of belts 3 & 4 idler pulleys groups
REPLACEMENT PROCEDURE SCHEDULE no. 10
Operation:
Belts 3 & 4 idler pulleys groups
replacement
Working area: i2000SR IM Mechanical Group: 625.102.00X
Electrical Group: 625.800.00X Part no.
579.440.00X
579.450.00X
Machine Status: Controlled shutdown and power disconnected
Skill Required: FSE (Field Service Engineer)
Time Required: TBD (To Be Determined)
Special Tools Required: None
Activity Type: Setting Control Cleaning ; Replacement
Intervention kind: Electrical ; Mechanical Fluidic Pneumatic
Daily Weekly Monthly
Quarterly Half yearly Yearly
Two-year After signalizing ; Because of failure
Frequency:
When necessary
WARNING: Potential Biohazard. This is an activity or area
where you may be exposed to potentially infectious
material. Refer to “Section 4 - Hazards and Warnings
” of
the Accelerator Service Manual
Reduce exposure by using proper personal protection
equipment and cleaning surfaces with 0.1% sodium
hypochlorite (bleach).
CAUTION: Moving Parts
The safety cover protection is not guaranteed if the
security devices are removed or bypassed. Use caution to
prevent injury caused by moving parts.
WARNING: Electrical Shock Hazard. Possibility of electrical
shock exists if procedural or engineering controls are not
observed.
WARNING: Pinch hazard
CAUTION: Class 2 Laser Radiation when open. Do not stare
into beam. Avoid eye exposure to laser light.
