i2000SR interface module Service Manual
Page 198 of 212 625798100.APS.5.doc
Tag Reader CAN BUS Board Firmware Installation
UPGRADE PROCEDURE SCHEDULE no. 21
Operation:
Tag Reader CAN BUS Board Firmware
Installation
Purpose:
This procedure is to be used to upgrade the firmware on the Tag
Reader CAN BUS Boards used on the workcell track and i2000SR
electronic box
Working area:
i2000SR IM
APS Track
Mechanical Group:
625.102.00X
580.100.00X
Electrical Group:
625.800.00X
580.100.00X
Part no. N/A
Machine Status: Paused
Skill Required: FSE (Field Service Engineer)
Time Required: TBD (To Be Determined)
Special Tools Required:
Infineon On-Chip Memory Programming Tool installed on a support
PC/Laptop (Memtool.exe)
Latest release of CAN BUS Firmware
Serial communication cables (9 pin, female/female, pins 2 and 3
reversed and pin 5 to 5)
Activity Type: ; Setting ; Control Cleaning ; Replacement
Intervention kind: ; Electrical Mechanical Fluidic Pneumatic
Daily Weekly Monthly
Quarterly Half yearly Yearly
Two-year After signalizing ; Because of failure
Frequency:
; When necessary
WARNING: Electrical Shock Hazard. Possibility of electrical
shock exists if procedural or engineering controls are not
observed.
