− Bar Code Scanner beeps once then twice.
− Pole Instrument Indicator Light turns RED
− Tag Reader LEDs turn on.
− Pole RED lamp blinks until the Master Slave to i2000SR
SCC communication check is passed.
• SCC CLI Edgeport port 1 (com 3)
• Master Slave Port 2 (CLI)
• SCC LAS Edgeport port 1 (com 6)
• Master Slave Port 1 (LAS)
NOTE:
The i2000SR IM will not initialize unless the cable check is
passed.
• After the pole lamp turns red and begins blinking, turn on
the System Control Center for the i2000SR analyzer.
• After the Snapshot screen on the System Control Center is
displayed at the APS, turn on the computer.
− During initialization, verify that the i2000SR IM Track is
initialized and the carrier queues are properly built.
− Instrument Indicator Red Lamp is illuminated
− Six (6) carriers at the Priority Gate (G8)
− Eleven (11) carriers at the Routine Gate (G7b)
− Four (4) carriers at Output Gate (G6)
• At the APS, LOGIN as FSE
• Select Configuration, System screen turn all Instrument
Off-line.
• Select Diagnostics, Track, Track Exercise.
• Enable Track Exercise and Random Use of Pit Lanes
• Select Start and then RUN.
• As carriers move along the track and enter the i2000SR
IM, verify the following:
− As carriers arrive at Instrument Gate G0 they are released.
− Carriers are smoothly diverted into the IM pit lane.
− As carriers arrive at Entry Gate G1, the IM belts are
turned ON and the carriers are released and routed into
IM Lane 1.
− Verify that the carriers move from track to Lane 1 without
interference.
