Technical specification
Subsystem 0072
8 Technical specification
8.1 Subsystem 0072
8.1.1 Electrical Characteristics
Mains voltage for the System
400 V 3N, 50/60 Hz
400 V 3~
480 V 3~
Long-time (positioning) 2 A 50/60 Hz.
Momentary (exposure):150 A, 50/60 Hz
(Short term peak value),
(recommended fuse 63 A, thermal breaker,
B curve.)
Class 1
Heat dissipation
1713 BTU/H
Generator
Series
and
Mains
Voltage
Minimum
Recom-
mended
Mains
Discon-
nect to
Generator
(15 ft/5 m
max)
Generator
Momenta-
ry Line
Current
Minimum
Recom-
mended
Generator
Service
Rating
Minimum
Recom-
mended
Distribu-
tion
Trans-
former
Rating
Minimum
Recom-
mended
Ground
Wire Size
Apparent
Mains Re-
sistance
50kW 400
VAC, 3p.
(13.3
mm
2
)
100 A 100 A 65 kVa
(13.3
mm
2
)
0.17 Ω
65kW 400
VAC, 3p.
(13.3
mm
2
)
125 A 100 A 85 kVa
(13.3
mm
2
)
0.13 Ω
80kW 400
VAC, 3p.
(13.3
mm
2
)
155 A 100 A 105 kVa
(13.3
mm
2
)
0.10 Ω
8.1.2 Environmental Requirements
Ambient transport and storage temperature
-25°C - +70°C
Ambient operating temperature
+10°C- +40°C
Transport and storage humidity (relative) 10-90%, non-condensing
Operating humidity (relative) 30-75% RH, non-condensing
Maximum transport and storage altitude
3000 m
Maximum operating altitude
3000 m
Maximum air pressure
700–1060 hPa
