3.7.5 XY Foot Control, Strip Type (Option)
Press and hold the foot control strip type (1) to release the brakes (X, Y) on the table top (2).
When activated, the table top can be moved manually (floating table top).
1
2
Z
Y
X
0
Fig. 3-41 Foot control strip type
1. XY foot control strip type (option) 2. Table top (X/Y)
