Technical specification
Table
8.4 Table
8.4.1 Column
Lowest table top position (from the floor to
the table top surface)
550 mm
Column (Z stroke)
380 mm
8.4.2 Table Top
Table top dimensions
2424 mm x 850 mm
Table top transparent area
2400 mm x 613 mm
Table top thickness
21,5 mm
Length of stroke, X direction
± 600 mm
Length of stroke, Y direction
± 150 mm
Movement range of the imaging unit
>650 mm
Movement range of the detector
up to 850 mm
8.4.3 Weight
Table
Approximately 150 kg
Imaging unit Approximately 21 kg
Table top
Approximately 47 kg
Maximum patient load
300 kg
8.4.4 Electrical Characteristics
Maximum power without external
electronics
500 W
