User Interface
Automatic Collimator Control
Wallstand/Table Stitching
The user must define the area that shall be captured in the stitching sequence.
When choosing Stitching mode, new information will be present on the manoeuver handle;
high (left) position, low (right) position, total length and number of exposures. The tube sup-
port moves to the pre-defined position for X, Y, Alpha, Beta and Wallstand (detector holder
for TableStitching). Z moves to the position received from the Image system (SID value for
TableStitching ).
To start the stitching procedure, press Start exam.
The movement for stitching is:
• From head to foot, for booth Wallstand and Table.
The operator sets the size of the stitching area (the composite image) by positioning the light
field.
Note!
A patient protection shall always be used at Wallstand examinations when performing stitch-
ing examinations.
For detailed information about the stitching operation, see the Operator’s Manual.
Exposure Validation
It is only possible to perform an exposure when the System is ready;
• indication light is fixed
• generator is enabled.
The exposure will be blocked and the user needs to activate the start button once more if; a
new parameter setting is received, the System is moved out from the start position, a colli-
sion when moving, patient position removed, or collimator size is changed.
3.2.8 Hospital manual
The hospital manual is reached by a activating the Hospital manual button for 1 second.
The hospital manual is selectable when a method book has been loaded to the display (per-
formed by service engineer)
Fig. 3-23 Hospital manual button
ARCOMA AB 1000-095-051-EN Rev. 1.1
Operation Manual
SWEDEN Page 60 2020-06-16
