Operating the System
Free Examination Procedures
4.8 Free Examination Procedures
4.8.1 Free Mode
4.8.1.1 General
The Free mode is designed for emergency examinations. The servo button cannot be acti-
vated in Free mode, consequently no automatic movement is available.
4.8.1.2 Flow of Operation
Select a Free mode examination.
The System display will display the following, see Fig. 4-23 Free mode display.
Fig. 4-23 Free mode display
• The stand will display H, distance to the floor.
• All movements are available.
4.8.1.3 Exposure
Exposure is possible when the OTC is not moving.
Note!
The OTC will automatically enter the “Free mode” at start-up.
4.8.2 Auto Position Mode
4.8.2.1 General
The Auto position mode is designed for emergency examinations or examination with a mo-
bile detector.
4.8.2.2 Pre-defined Auto Positions
When the auto position mode is selected, the OTC will go to a predefined position in the
room.
Operation Manual
1000-095-051-EN Rev. 1.1 ARCOMA AB
2020-06-16 Page 109 SWEDEN
