Safety
Mechanical Safety
2.9.3.1 Detector Unit, Table
WARNING!
The detector must not be dropped.
Handle with care, to avoid detector malfunction causing delayed diagnostics.
The manoeuver control (2) controls the detector holder brake.
When the manoeuver control is activated the brakes are released in order to move the detec-
tor holder (1). Power loss will also release the brakes enabling moving the detector holder.
The brake is normally activated, at power loss the brake is released.
Fig. 2-5
1. Detector holder 2. Manoeuver control
Operation Manual
1000-095-051-EN Rev. 1.1 ARCOMA AB
2020-06-16 Page 23 SWEDEN
