Arctic Cat 2007 - Front Differential;Rear Drive Lubricant

2-10
9. Unscrew the oil level stick and wipe it with a
clean cloth.
10. Install the oil level stick until the threads touch
engine case.
 NOTE: The oil level stick should not be threaded
into the case for checking the oil level.
11. Remove the oil level stick; the engine oil level
should be above the illustrated “L” mark but not
higher than the illustrated “F” mark.
ATV-0100
12. Inspect the area around the drain plug and oil fil-
ter for leaks.
Front Differential/Rear
Drive Lubricant
Check and change the lubricant according to the
Periodic Maintenance Chart. When changing the
lubricant, use approved SAE 80W-90 hypoid gear
lube. To check lubricant, use the following proce-
dure.
1. Remove the fill/level plug; the lubricant level
should be 1 in. below the plug threads.
PR046A
2. If low, add SAE approved 80W-90 hypoid gear
lube as necessary.
PR065A
To change the lubricant, use the following proce-
dure.
1. Place the vehicle on level ground.
2. Remove each fill/level plug.
3. Drain the lubricant into a drain pan by removing
in turn the drain plug from each.
ATV0082A
! CAUTION
Do not over-fill the engine with oil. Always make
sure that the oil level is above the
“L” mark but not
higher than the
“F” mark.
