Arctic Cat 2007 - Torque Specifications

10-2
Torque Specifications
DRIVE TRAIN COMPONENTS
Part Part Bolted To
Torque
kg-m ft-lb
Engine Cradle Engine 5.5 40.0
Engine Cradle Rubber Mount 3.5 25.0
Front Differential* Frame/Differential
Bracket
6.2 45.0
Rear Output Flange Rear U-Joint
Flange
5.5 40.0
Input Housing Differential
Housing
2.9-3.5 21.0-25.0
Diff Housing Cover*** Differential
Housing
2.9-3.5 21.0-25.0
Drive Bevel Gear Nut*** Shaft 11.0-13.0 79.5-94.0
Differential Gear
Case***
Hub 2.3-3.0 16.5-22.0
Lock Collar Differential
Housing
17.3 125.0
Hub Nut Front/Rear
Shaft/Axle (min)
27.6 200.0
Oil Drain Plug Front Differential/
Rear Drive
0.5 3.5
Oil Fill Plug Front Differential/
Rear Drive
2.2 16.0
Oil Drain Plug Engine 2.2 16.0
Inspection Plug Rear Drive 0.5 3.5
Wheel Hub 5.5-6.2 40.0-45.0
Front Shaft Flange Front U-Joint 2.8 20.0
EXHAUST COMPONENTS
Exhaust Pipe Engine 2.8 20.0
ELECTRICAL COMPONENTS
Coil* Frame 1.1 8.0
Ground Wire Engine 1.1 8.0
STEERING COMPONENTS
Steering Wheel Shaft** Steering Wheel 3.5 25.0
Steering Wheel Shaft Intermediate Shaft
(Upper)
3.5 25.0
Intermediate Shaft
(Lower)
Steering Pinion
Shaft
3.5 25.0
Rack and Pinion Frame 6.9 50.0
Tie Rod End Knuckle 4.2 30.0
Jam Nut Tie Rod End 1.1 8.0
BRAKE COMPONENTS
Part Part Bolted To
Torque
kg-m ft-lb
Brake Disc* Hub 2.1 15.0
Brake Hose Caliper 2.8 20.0
Brake Hose Master Cylinder 2.8 20.0
Master Cylinder Frame 3.5 25.0
Parking Brake
Mechanism
Frame 2.8 20.0
Hydraulic Caliper Knuckle 2.8 20.0
Rear Caliper Rear Drive Gear Case 2.8 20.0
Drive-line Brake Rear Drive Input Flange 1.7 12.0
CHASSIS COMPONENTS
Shift Lever* Shift Axle Bracket 2.8 20.0
SUSPENSION COMPONENTS (Front)
A-Arm Frame 4.6 33.0
Ball Joint Cap Screw Knuckle 4.8 35.0
Shock Absorber (Upper) Frame 4.6 33.0
Shock Absorber (Lower) Upper A-Arm 4.6 33.0
Knuckle A-Arm 4.6 33.0
SUSPENSION COMPONENTS (Rear)
Axle Retainer Assy Axle Housing 5.5 40.0
Sway Bar Bracket Frame 4.6 33.0
A-Arm Frame 4.6 33.0
Shock Absorber (Upper) Frame 4.6 33.0
Shock Absorber (Lower) Lower A-Arm 2.8 20.0
Knuckle A-Arm 4.6 33.0
Cargo Box Hinge Cargo Box Frame 2.8 20.0
Cargo Box Cargo Box Frame 2.8 20.0
Latch Pivot Bushing Cargo Box Frame 2.1 15.0
Latch Striker Cargo Box Liner 1.4 10.0
CANOPY ASSEMBLY
Front/Rear Canopy Tube Arm Rest/Steering Post
Support
2.8 20.0
Top Canopy Support Front/Rear Canopy
Tubes
1.1 8.0
Rear Canopy Tube Lower Canopy Support 1.1 8.0
