10-3
10
* w/Blue Loctite #243
** w/Red Loctite #271
*** w/Green Loctite #609
ENGINE/TRANSMISSION
Part Part Bolted To
Torque
kg-m ft-lb
Clutch Shoe** Crankshaft 31.8 230.0
Clutch Cover/ Housing
Assembly
Crankcase 1.1 8.0
Crankcase Half (6 mm) Crankcase Half 0.9-1.3 6.5-9.5
Crankcase Half (8 mm) Crankcase Half 2.8 20.0
Cylinder Head
(Cap Screw)
Crankcase 5.5 40.0
Cylinder Head (6 mm) Cylinder 1.1 8.0
Cylinder Head (8 mm) Cylinder 2.5 18.0
Cylinder Head Cover Cylinder Head 1.15 8.5
Driven Pulley Nut Fixed Face 13.5 97.5
Fixed Driven Clutch Shaft 13.5 97.5
Ground Wire Engine 1.1 8.0
Magneto Cover Crankcase 1.1 8.0
Mechanical Water Pump
Impeller
Pump Shaft 1.05 7.5
Movable Drive Face Driveshaft 10.4-11.8 75.0-85.0
Oil Pump Drive Gear Crank Balancer
Shaft
8.5 61.5
Output Shaft Gear Output Shaft 8.5 61.5
Outer Magneto Cover Right-Side Cover 0.8 6.0
Rotor/Flywheel Nut Crankshaft 14.5 105.0
Cam Sprocket** Camshaft 1.35 9.8
Starter Cup Crankshaft 3.8 27.5
V-Belt Cover Crankcase 1.1 8.0
Plenum*** Engine 1.1 8.0
Spark Plug Engine 1.7 12.0
