General Specifications*
* Specifications subject to change without notice.
** 1 inch below plug threads.
CARBURETOR
Type Keih i n C V K 36
Main Jet 132
Slow Jet 40
Low Speed Fuel Screw Setting
(turns)
1 1/4
Jet Needle Fixed
Needle Jet 6.0/4.0
Idle RPM 1250-1350
Starter Jet 85
Float Arm Height 17 mm (0.7 in.)
ELECTRICAL
Ignition Timing 10° BTDC @ 1500 RPM
Spark Plug Type Champion RG6YC
Spark Plug Gap 0.7-0.8 mm
(0.028-0.032 in.)
Spark Plug Cap 3750-6250 ohms
Ignition Coil (primary)
Resistance
(secondary)
Less than 1 ohm
(terminal to ground)
5200-7800 ohms
(high tension - plug cap
removed - to ground)
Ignition Coil Peak Voltage
(primary/CDI)
142.4-213.6 DC volts
(blue/white to ground)
Magneto Coil (trigger)
Resistance
(source)
(charging)
160-240 ohms
(green to blue)
Less than 1 ohm
(yellow to white)
Less than 1 ohm
(black to black)
Magneto Coil Peak (trigger)
Voltage
(source)
4.2-6.3 volts
(green to blue)
0.40-0.62 volt
(yellow to white)
Stator Coil Output (no load) 60 AC volts @ 5000 RPM
(black to black)
Magneto Output (approx) 325W @ 5000 RPM
CHASSIS
Dry Weight (approx) 526 kg (1160 lb)
Length (overall) 292 cm (115 in.)
Height (overall) 197 cm (77.5 in.)
Width (overall) 156 cm (61.3 in.)
Suspension Travel (front)
(rear)
25.4 cm (10 in.)
25.4 cm (10 in.)
Brake Type Hydraulic
Wheelbase 190 cm (75 in.)
Tracking (front)
(rear)
128.3 cm (50.5 in.)
123.2 cm (48.5 in.)
Tire Size (front)
(rear)
26 x 9-14
26 x 11-14
Tire Inflation Pressure 0.70 kg/cm² (10 psi)
Turning Radius 3.3 m (10.8 ft)
MISCELLANY
Gas Tank Capacity (rated) 31 L (8.2 U.S. gal.)
Coolant Capacity 2.9 L (3.0 U.S. qt)
Differential Capacity
275 ml (9.3 fl oz)**
Rear Drive Capacity 250 ml (8.5 fl oz)**
Engine Oil Capacity 2.5 L (2.6 U.S. qt)
Gasoline (recommended) 87 Octane Regular
Unleaded
Engine Oil (recommended) SAE 5W-30
Differential/Rear Drive
Lubricant
SAE Approved
80W-90 Hypoid
Belt Width 35.0 mm (1.38 in.)
Brake Fluid DOT 4
Taillight/Brakelight 12V/8W/27W
Headlight 12V/27W (2)
Starting System Electric
