4 External Devices
This chapter will quickly describe the external devices that could be connected to a DIVA unit. It won't
speak about external contact or button that also could be used.
For more information about those devices, please visit ATEÏS website
.
4.1 Fireman Microphone
The Fireman Microphone SHM 1 is a small compact microphone dedicated to security calling. It is a
totally monitored microphone with internal resistor network to detect four different states (Shortcut,
Closed Contact, Open Contact, Absent). Firemen Microphone SHM 1 for All call, group or zone calls.
The EN 60849 surveillance is realised thanks to the DIVA SEC interface.
4.2 PSS
The PSSDT paging microphone can be configured either using a PC computer, or by using control
keys and the front LCD screen of the SINAPS module to which it is connected. Access can be
password-protected.
All parameters needed for site operating can be programmed: zones assigned to the different buttons,
name of zones, zone groups, priorities, access to different messages, levels adjustments, pre-call
chime, press-to-talk, music ON/OFF and music routing.
Its large LCD screen provides an overall view of busy zones and active sources. A VU meter controls
the microphone presence and modulation level.
A built-in loudspeaker makes it possible to listen to all system-generated messages and
announcements.
The PSSDT console is SINAPS security system interface and is fully monitored (microphone capsule,
power supply, touchscreen, audio and RS485 connections). Any system faults are detected, located
and indicated clearly on the screen.
Different product references are available to suit all site sizes:
