7.Check the free clearance of left/right front
wheel fork
Inspection step:
a:Check the parts
¢Ùof let/right front wheel
fork on the frame, if it is bend, crack or worn
repair or replace the frame.
b:Check the torque value of locking nut on
the left/right front wheel fork
Attached:Nut torque value:45Nm
c:Move the left/right front wheel fork from one
side to another to check its side clearance. If
the side clearance is very obvious replace bush-
ing sub-assembly or a set of front wheel fork.
d:Move the left/right front wheel fork up and
down to check its vertical clearance. If the
vertical moving is tight, limited or uneven, re-
place the bushing sub-assembly or whole front
wheel fork.
8.Take off nut
¢Ù, bolt¢Ú, left/right front wheel
fork
¢Ûand bushing sub-assembly¢Ü.
- 102 -
