ATV 200 - Section 10 Troubleshooting; (I)If Indicated Lamp Is out of Work

Section 10 Troubleshooting
(I)If indicated lamp is out of work
Steps
Check:
1.Safety
2.Battery
3.Front switch
4.Coupling of wires
(Whole signal system)
Remark:
.Remove the following parts before
troubleshooting.
1)Cushion
2)Front frame.
3)Front pedal
.Use special toolings for trouble shooting
Correct
1.Safety
Refer to “Inspection of switch”
2.Battery
.Check the battery condition
Refer to “Inspection of battery”in chapter 3.
Voltage of open circuit
12.8V or more at at 20¡æ(68¡ãF)
*
Correct
Pocket multimeter
No electrification
Replace fuse
Incorrect
.Clean battery terminal
.Recharge or replace battery
- 137 -
