ATV 200 - (V) Manual Starting Mechanism and Others

1. Mount:
¡¤Coil spring backboard assy
Caution
Caution
Caution
Hang the coil spring hook hanger ¢Úinto the split
of spring backboard, and wind the coil spring
in counterclockwise.
2. Install:
¡¤Washer ¢Ù
¡¤Coil spring backboard assy ¢Ú
End of the coil spring is hung the inner race of
left side-cover coil spring
3. Wind the rope in the drive disc groove 4
circles by clockwise.
4. Lubricate:
¡¤Coil spring backboard assy
¡¤Drive disc
5. Mount:
¡¤Drive disc¢Ù
The projection ¢Ûneed to be mounted into two
hole groove ¢Úand the coil spring hook hanger
¢Ý also need to be mounted into the hole groove
¢Ü.
1
2
¢Ù
¢Ú
¢Ù
¢Ú
¢Û
¢Ü
¢Ù
¢Ú
¢Û
¢Ü
¢Ý
Apply grease
(V) Manual starting mechanism and others
- 206 -
