ATV 200 - (II)Inspection of Fuse

5.Inspection of battery
If damaged, replace it
6.Installment of battery¢Û
7.Connect
.Battery electrode(positiove electrode ¢Ù
negative electrode ¢Ú)
First connect the positive electrode¢Ù
8.Installment:
a.Battery clamp plate ¢Ü
b.Cushion
(II)Inspection of fuse
Close the main switch when checking or re-
placing the fuse, otherwise, it will cause the
short circuit.
1.Inspection steps
.Remove the fuse ¢Ù
.Connect the small-size test instrumentation to
measure if the fuse is connected well.
Set the test instrumentation at the postion of
“52 ¡Á1”
.If the indicating needle indicates toward ¡Þ,
the fuse has broken needing to be replaced.
Small size test instrumentation:
9/N.YU-03112
90890-03112
Caution
Caution
¢Ü
¢Ù
¢Û
¢Ú
¢Ù
- 50 -
