II.Inspecting procedures
1.Check
Front wheel:refer to “Tire inspection”and “Hub
inspection”of chapter2.
2.Measure
Radial runout of front wheel:If exceeding the
specified limit, replace the front wheel or check
the bearing clearance(¢Ùin figure)
Attached:Rim runout limit:
Radial runout 2.0mm(¢Úin figure)
End face runout 2.0mm(¢Ûin figure)
3.Check:
Tire surface:If worn or damaged, replace it.
Refer to “Tire inspection”of chapter2.
Install the tire according to direction ¢Ùof
“ROTATION”mark on the tire.
The tire assembly should be conducted on spe-
cial equipment. After replacing the tire, con-
duct curvilinear motion carefully. Must ensure
the tire on the correct position in rim. Other-
wise may cause damgage of motorcycle or
driver.
Warning
Caution
- 78 -
