ATV 200 - II.basic Specification

II.Basic specification
- 9 -
Item
Item
Specification
Specification
Dimension:
Overall length 1940mm
Overall width 1050mm
Overall height 1160mm
Height of cushion 810mm
Axle base 1160mm
Front wheel distance 785mm
Rear wheel distance 770mm
Min.ground clearance 155mm
Min.turning radius 2900mm
Basic weight:
Engine oil(with full tank) 220kg
Engine Single-cylinder,air-cooled four stroke
Displacement 193.2ML
Cylinder borestroke 63 ¡Á62mm
Compression ratio 9.0:1
Starting system Electric starter or handoperated starter
Lubrication system Pressure splash
Engine oil SAE20W/40,SAE15W/40
Classfication of recommendedengine oil Model SE,SF,SG or above model
Periodic oil replacement 1.0L
Replace filter 1.1L
Overall capacity 1.1L
Oil capacity of gearbox 0.27L
Model: SAE80API¡°GL-4”Gear oil of
standard double curved face
Capacity of main fuel tank 12L.Non-lead gasolining No.90#
Capacity of reserved fuel tank 1.6L
Carburetor:
Type PZ30(INJECT PZ30)
Type of spark plug D8EA
Clearance of spark plug 0.6-0.7mm
Type of clutch Wet hand centrifugal type
Output
Primary reduction system Gear driving
Reduction ratio 3.333
Secondary reduction system Axle driving
Reduction ratio 3.742
Output type Non-cycle,five gear forward,gear back
Operation Left-foot operation
Shifting type
1st speed 2.769
2nd speed 1.882
3rd speed 1.400
4th speed 1.130
5th speed 0.960
Reverse gear 34.427
Frame
Bracket Steel tube
Caster angle 13¡ã
Toe-in of tire 0-5mm
Tire
Type Vacuum
Specification of front wheel AT23 ¡Á7-10
Specification of rear wheel AT22 ¡Á10-10
Pressure of front wheel 20Kpa
Pressure of rear wheel 25Kpa
Brake:
Type of front brake Drum brake(full-closed type)
Operation type Right-hand operation to brake
Type of rear brake Drum brake(full-closed type)
Operation type Right-foot to brake
Front suspension Independent suspension device
Rear suspension Rear centering shock absorbing type
Specification of shock absorber
Front shock absorber spring
Rear shock absorber spring
Electric system:
Ignition system C.D.I
Magneto system A.C magneto
Battery/capacity Free of maintenance,
12V,14AH
Headlight 12V,30W/30W ¡Á2
Taillight 12V,10W¡Á1
Neutral indicator 12V,3W ¡Á1
Reverse indicator 12V,3W ¡Á1
High-beam indicator 12V,3W ¡Á1
