- 32 -
Section 2 Diassembly and assembly of
Cushion, Fender and Fuel tank
(1) Cushion
1.Disassembly
(1) Place the vehicle on the horizontal ground.
(2) Disassemble the cushion ¢Ù
Pull the cushion lock lever ¢Úupward, then
raise the tail part of cushion. By that, you can
disassemble the cushion.
2.Installation
Firstly insert the support lug on the front end
of cushion into the spigot of frame, then press
down the rear part. Pay attention to confirm
if the cushion is installed firmly.
¢Ù
¢Ú
