Section 3 Troubleshooting the ignition system failure
If the ignition system does not work(no spark or spark stops)
1.Spark plug
2.Ignition park clearance
3.Resistance value of spark plug cap
4.Resistance value of ignition coil
5.Engine stop switch
Step
Check
6.Main switch
7.Resistance value of triggering coil
8.Resistance value of charge coil
9.Circuit connection (whole ignition system)
.Remove following components before
troubleshooting:
1)Cushion
2)Front frame
3)Front fender
Remark
Power spark tester:
Ignition tester:
Pocket multimeter:
Spark plug clearance
0.6~0.7mm(0.024~0.028 in)
correct
1.Spark plug
.Check the spark plug condition
.Check the spark plug type
.Check the spark plug clearance
Refer to chapter 3 “Check spark plug”
Check and repaire with following special tools.
Standard spark plug
D8EA
Incorrect
Repair or replace the spark plug
- 117 -
