ATV 200 - Chapter I General description

Chapter I General description
Section 1Description
1.Front wheel
2.Headlight
3.Drive select lever
4.Shift pedal
5.Fuel cock
6.Hand-operated lever
7.Air chock
8.Tail light
9.Rear wheel
10.Rear luggage carrier
11.Exhaust silencer
12.Cushion
13.Fuel tank cover
14.Rear brake pedal
15.Front luggage carrier
16.Clutch handle
17.Main switch lock
18.Throttle grip
19.Right lever of front brake
20. Left switch unit
Caution:
The ATV you purchased maybe slightly differ from the pictures in the manual due to
improvement or other changement.
1
2
3
4
5
6
7
8
9
10 11
12
13
14
15
- 1 -
