ATV 200 - Section 2 Front Wheel and Front Brake; (I)Disassembly

Section 2 Front wheel and Front Brake
Technical Parameter
Ser No.
1
2
3
4
5
6
7
Item
Parameter
AT23¡Á7-10
5.5¡Á10
20KPa(Standard value)
17KPa(Min value)
23KPa(Max value)
2mm
2mm
2mm
2mm
16mm
Tire specification
Rim dimension
Runout
Tire air pressure(normal
temperature)
Tire wear limit value
Wear limit value of friction wafer
Wear limit value of front brake hub
Standard value
Min value
Max value
Radia runout
End face runact
(I)Disassembly
1)Pay attention to the following points when
disassembling front wheels
a:Place the vehicle on a horizontal ground, and
press down the front brake attaching clamp
¢Ù.
b.Loosen the connecting nut¢Ùof front &rear
wheel on the front wheel.
c:Place a bracket under the frame to pick up
the front wheels.
Support the vehicle firmly and avoid dropping
down.
2)Disassemble the connecting nut ¢Ùof front
&rear wheel.
Warning
¢Ù ¢Ú
- 76 -
¢Ù
