(VI)Adjustment of speed limitator:
The speed limitator can limit the throttle in full
opening condition when the throttle grip is
pulled to the Max position, screwing the ad-
juster inward can stop increasing the speed.
1.Adjust speed limiting length@
Adjustment steps:
a.Loosen the locking nut ¢Ù
b.Adjust the adjusting screw ¢Úclockwise or
counterclockwise to make @ obtain the speci-
fied length of 12mm.
c.Lock the locking nut ¢Ù
A.For the beginner of driving, pay extral at-
tention to screw in the speed limitator inward
and screw out with improvement of driving
skill, never remove the adjusting screw of
speed limitator.
b.For the correct throttle grip operation, never
screw out the adjuster to exceed 12mm, and
adjust the free clearance of throttle grip to 3-
5mm.
Warning
- 57 -
¢Ù ¢Ú
