(VII)Installation:
The procedure is the reversal of
“disassembly”.But pay attention to following
points:
1.Install the needle bearing(small)on main driv-
ing gear:
Procedures:a.Warm the case body to 150¡æ
b.Assemble the out circle of needle bearing
with proper holddown.
c.Install the inner circle of the needle bearing
onto the shift gear.
2.Install oil seal¢Ù
3.Install the outer circle of the needle bearing
(bigger) ¢Úof shift gear onto the driving gear
case body.
Must use new oil seal
4.Install main driving gear ¢Ùpad ¢Úand
bearing¢Û, and install bearing gasket¢Ü. Cal-
culate the size of pad.
The bearing gasket is left handed, so
tighten it up by rotating counterclockwise.
Before installing the bearing gasket, ap-
ply grease on O-ring.
When installing the bearing gasket, tighten
it with special tool.
Caution
Warning
¢Ù
- 75 -
