2.Choice of shift gear pad
Shift gear pad ¢Ù
Choosing procedures:
Work out the pad thickness “B”front follow-
ing formula
“B”= + - +
=45.5adds or subtracts the number en-
graved on the driving gear case body.
=1 adds or subtracts the number engraved
on the driving gear case cover.
=35 adds or subtracts the number on the
shift gear
=bearing thickness(regarding
unchangeable)=“11.00mm”
For example:
1)The number engraved on the driving gear
case body is “0.7”
=45.5+0.07=45.57
2)The number engraved on the driving gear
case cover is “06”
=1+0.06=1.06mm
3)The number engraved on the driving gear
case cover is “-05”
=35-0.05=34.95
4) 11.00
5)So the pad thickness “B”
“B”=(45.57+1.06)-(34.95+11)=0.68
The pad has following thickness.
Number on percent digit
0 ¡¢1 ¡¢2
3 ¡¢4 ¡¢5 ¡¢6 ¡¢7
8 ¡¢9
Amending value
0
5
10
Thickness
mm
Main driving gear pad
0.25 0.40
0.30 0.50
- 74 -
