9. Mount:
¡¤Washer ¢Ù
¡¤
Washer ¢Ú
¡¤Reverse lever system ¢Ü
Caution
Coat sealing gum on the bolt ¢Û
10. Mount:
¡¤Manual starting system ¢Ù
(VI) Mount the engine on the finished vehicle
Its steps is opposed to steps of “Engine Dis-
assembly”
Caution
Support motorcycle firmly for avoiding turn-
ing over.
1. Mount:
¡¤Engine
Mount the engine from right side of frame.
2. Mount:
¡¤Bolt ¢Ù(Installation position of engine-rear
lower)
¡¤Bolt ¢Ú(Installation position of engine-rear
upper)
¡¤Bolt¢Û(Installation position of engine-front)
¡¤Bolt¢Ü(Installation position of engine-top)
Caution
¡¤Mount all the installing bolts from right side
of motorcycle
¡¤Turn the nut and bolt temporarily, but don’ t
fasten them at this time.
¢Ù
7Nm
6 places
- 208 -
