3. Mount:
¡¤Drive assy of rear wheel and rear wheel fork
Assembly steps:
1) Lubricate following parts before mounting
the rear wheel fork
¡¤Bearing ¢Ù
¡¤Oil sealing ¢Ú
¡¤Bushing ¢Û
¡¤Coupling bolt of rear arm ¢Ü
¡¤Spline of drive shaft ¢Ý
Spline of main drive gear¢Þ
Lubrication oil:
Lithium base lubrication oil
2) Mount the drive shaft ¢ßon the spline ¢Þof
main drive gear.
3) Pull rear wheel fork forward, and mount
drive shaft ¢ß on the rear joint of direction knot
¢à.
4. Connect:
Rubber bushing etc ¢Ù.
5. Mount:
¡¤Coupling bolt ¢Úof rear arm
¡¤Rear arm nut ¢Û
¡¤Coupling bolt ¢Üof rear arm
Turn the rear arm shaft bolt and rear arm shaft
nut temporarily, and don’t fasten them at this
time.
6. Check:
¡¤Operation of drive shaft
Checking steps:
¡¤Hold the front wheel and put the proper
bracket on the frame for lifting rear wheel
¡¤Front and rear turning rear wheel
¡¤Front and rear turning rear wheel
Check the operation of driving shaft. If the op-
eration is not good, check the installation of drive
shaft again.
Caution
- 209 -
