Section 6 Wiring diagram of ATV
1.Technical explanation
A Main switch wire, indicator wire, mile-
age meter wire (mounting digital mileage
meter) must be put throught the guide grip of
holding seat of steering bar. (see fig.1)
B Rear brake vent-pipe, carburetor vent-
pipe and vent-pipe of rear driving gearbox must
be inserted into the hole of supporting pad of
vent-pipe.(see fig.1, also see view D)
C Neutral and reverse switch wire,
mileage meter wire(mounting with digital
mileage meter) should be fixed with bands
here.(see fig.1)
D After putting overflowing pipe of car-
buretor through two rear fixing part of engine
(on the frame), then put it in the proper posi-
tion between engine and rear arm. Note: Over-
flowing pipe be unblocked.(see fig.1)
S After putting rear brake cable, throttle
cable, wire of starting motor and mileage meter
(mounting with digital mileage meter )through
wire hook2, wire hook 2should be bent ac-
cording to the method of view A.
P In this position, starting motor wire
and mileage meter wire(mounting with digital
mileage meter)must be put through the hole of
plastic grip in the fuel tank support of frame..
(see view B-B)
R In here, rear brake cable, rear brake
vent-pipe and mileage wire(mounting with digi-
tal mileage meter)must be first put through wire
hook 2, then connect with respective match-
ing unit.(see fig. B-B)
Q In here, wire of reverse switch neutral
switch, and mileage meter (mounting with digi-
tal mileage meter)must be fixed with bands.
(see fig.B-B)
T When assembling the wire of ser. No.
14 and No.15.don’t need to put through the
guide clip of holding seat of steering bar.(see
fig.E-E)
W After putting the vent-pipe of tank
through the hole of main switch, lead it to the
lower of right side of steering bar, then put it
through the wire hook on the frame.
Note: Hose must be unblocked.(see fig.
E-E)
V The leading wire on the switch units of
steering bar, must be bound with band,(see fig.
G-G)
E After the vent-pipe of front brake is put
through plastic clip hole on the frame, surplus
portion should be put in the proper position of
frame.(see fig.2)
G After the vent-pipe of battery is checked
and no twist is found here, then insert it in the
presetting hole of rear fender.(If free of main-
tenance battery is used, then this item of re-
quirement doesn’t need.)(see fig.3)
H Wire of rear brake cable, rear brake
vent-pipe and mileage meter(mounting with digi-
tal mileage meter)should be put through the cable
frame welded on the frame in here.(see fig.3)
F In here, wire of starting motor must
be first put through the plastic clip on the
frame, then connect with the matching units.
(see fig.3)
L Vent-pipe of battery should be put
through the plastic clip fixed on the frame.(see
fig..)(If free of maintenance battery is used,
then this item of requirement doesn’t need.)
K In here, wire of throttle cable, rear
brake cable and mileage meter(mounting with
digital mileage meter )should be put through the
cable guide frame welded on the frame.
(Throttle cable
(I)Technical explanation and requirement, details of relative component.
- 16 -
