6. Mount:
¡¤Torsion spring (starting ratchet pawl)¢Ù
¡¤Starting ratchet pawl ¢Ú
¡¤Hog ring ¢Û
¡¤Compress spring ¢Ü
¡¤Guide plate ¢Ý
¡¤Screw pin ¢Þ
When mounting torsion spring (starting ratchet
pawl), make the end ¢ßof torsion spring align
to groove on the drive disc.
Caution
7. Turn the drive disc 3 circles by clockwise,
and pre-tighten the coil spring.
8. Mount:
¡¤Starting lever ¢Ù
¡¤Cover ¢Ú
Make the rope accross the hole of left side,
and knit it in order to the rope is not pulled into
left side cover.
¡¤After kniting ¢Ü, and untie it ¢Û.
Caution
¢Û
¢Ý
12Nm
¢Þ
¢Ú
¢Ù
¢Ù
¢Ú
¢Û
¢ß
a
¢Ü
¢Û
¢Ú
¢Ù
¢Ü
- 207 -
